Cloud Service
EV OS

Maximum Output Power
240 kW

Output Power
CCS1: 300 A @200~950 Vdc
CHAdeMO: 200 A @200~500 Vdc

Vehicle Connector
CCS1, CHAdeMO

Cord length
15 feet / 4.5 m

Input Power
3-phase, 5-wire, 480 Vac, 261 A maximum

Efficiency
≥ 94%

Grounding System
TN, TT, IT

V2G Communication Interface
ISO 15118

Communication Protocol
OCPP 1.6 JSON

Connectivity
Ethernet, Wi-Fi, 4G

RFID
RFID ISO/IEC 14443 A/B

NEMA enclosures (NEMA)
NEMA 3R

Impact Protection
IK10

Ingress Protection(IP)
IP55

Electrical protection
Over voltage protection, over current protection, over power protection, over temperature protection, under voltage protection, surge protection device, insulation monitoring device, short circuit protection, over power protection

Operating Temperature
-22° to 122° F / -30° to 50° C

Dimensions

31.5 (W) x 74.8 (H) x 25.6 (D) in
800 (W) x 1900 (H) x 650 (D) mm

Weight
1,686 lbs / 765 kg

Certifications
UL, cETLus
